The ZZ5538A is a complete integrated 5 GHz Power Amplifier Module (PAM) for 802.11ax 1024 QAM applications and systems. The DC power detector is included to provide closed-loop power control within the system. The ZZ5338 is available in a 20-pin 4.0*4.0*0.75mm Quad Flat No-lead (QFN) package.
The ZZ5538A is a complete integrated 5 GHz Power Amplifier Module (PAM) for 802.11ax 1024 QAM applications and systems. The DC power detector is included to provide closed-loop power control within the system. The ZZ5338 is available in a 20-pin 4.0*4.0*0.75mm Quad Flat No-lead (QFN) package.
5 V Supply Voltage
Fully Matched Input and Output
Supports 802.11ax/ac: Output Power:
+21dBm, -43dB DEVM, MCS11
+23.5dBm, -40dB DEVM, MCS11
+24.5dBm, -35dB DEVM, MCS9
+25.5Bm, -30dB DEVM, MCS7
Transmit Gain: 30dB
Integrated DC Power Detector (Voltage Output)
20-pin QFN 4.0 × 4.0 × 0.75mm, MSL3
RoHS Compliant & Halogen Free
802.11ax Networking Systems
WLAN-Enabled Wireless Video Systems
Tablets, Notebooks
Wireless Routers, Access Points, Wireless Gateways
Mobile Devices, Customer Premise Equipments (CPE)
802.11ax PC Cards; PCMCIA Cards;
Mini-Cards and Half Mini-Cards
