The ZZ5535 is a complete integrated 5GHz Front-End Module (FEM) for 802.11ax 1024 QAM applications and systems. It includes a high- linear 5GHz power amplifier (PA) with power detector, low-noise amplifier (LNA) with bypass capability, and single pole double throw switch (SPDT).
The LNA and PA disable functions ensure low leakage current in off mode. An integrated power detector is included to provide closed-loop power control within the system. The ZZ5535H1 is available in a 16-pin 3.0×3.0×0.75 mm Quad Flat No-lead (QFN) package.
The ZZ5535 is a complete integrated 5GHz Front-End Module (FEM) for 802.11ax 1024 QAM applications and systems. It includes a high- linear 5GHz power amplifier (PA) with power detector, low-noise amplifier (LNA) with bypass capability, and single pole double throw switch (SPDT).
The LNA and PA disable functions ensure low leakage current in off mode. An integrated power detector is included to provide closed-loop power control within the system. The ZZ5535H1 is available in a 16-pin 3.0×3.0×0.75 mm Quad Flat No-lead (QFN) package.
5 V Supply Voltage
Integrated High-performance 5 GHz PA, LNA with Bypass, and SPDT T/R Switch.
Fully-matched Input and Output
Supports 802.11ax/ac: Output power:
+20 dBm, -43 dB DEVM, MCS11
+22 dBm, -40 dB DEVM, MCS11
+23 dBm, -35 dB DEVM, MCS9
+25 dBm, -30 dB DEVM, MCS7
Transmit Gain: 29 dB
Noise Figure: 2.1 dB
Receive Gain: 15 dB
Bypass Loss: 9 dB
Integrated DC Power Detector (Voltage Output)
16-pin QFN 3.0×3.0×0.75 mm, MSL3
RoHS Compliant & Halogen Free
802.11ax Networking Systems
WLAN-enabled Wireless Video Systems
802.11ax PC Cards
PCMCIA Cards
Mini-cards and Half Mini-cards
Copy product links
Long by picture save/share
Application Field
WIFI wireless interconnection terminal
WIFI wireless internet terminal
High-end routers/AP devices
Wireless interconnection of data centers
